B-63944EN-2/02 PROGRAMMING 4.COORDINATE VALUE AND DIMENSION

- 33 -

4.1 POLAR COORDINATE COMMAND (G15, G16)

The end point coordinate value can be input in polar coordinates

(radius and angle).

The plus direction of the angle is counterclockwise of the selected

plane first axis + direction, and the minus direction is clockwise.

Both radius and angle can be commanded in either absolute or

incremental programming (G90, G91).

Format

Gxx Gyy G16; Starting the polar coordinate

command (polar coordinate mode)

G00 IP_ ;

: Polar coordinate command

G15; Canceling the polar coordinate

command (polar coordinate mode)

G16 : Polar coordinate command

G15 : Polar coordinate command cancel

Gxx : Plane selection of the polar coordinate command

(G17, G18 or G19)

Gyy : Center selection of the polar coordinate command

(G90 or G91)

G90 specifies the origin of the workpiece

coordinate system as the origin of the polar

coordinate system, from which a radius is

measured.

G91 specifies the current position as the origin of

the polar coordinate system, from which a radius is

measured.

IP_ : Specifying the addresses of axes constituting the

plane selected for the polar coordinate system,

and their values

First axis : radius of polar coordinate

Second axis : angle of polar coordinate
