B-63944EN-2/02 APPENDIX A.PARAMETERS

- 315 -

A.3 STANDARD PARAMETER SETTING TABLES

This section defines the standard minimum data units and valid data

ranges of the CNC parameters of the real type, real machine group

type, real path type, real axis type, and real spindle type. The data type

and unit of data of each parameter conform to the specifications of

each function.

NOTE

1 Values are rounded up or down to the nearest

multiples of the minimum data unit.

2 A valid data range means data input limits, and

may differ from values representing actual

performance.

3 For information on the ranges of commands to the

CNC, refer to Appendix D, "Range of Command

Value."

(A) Length and angle parameters (type 1)

Unit of data Increment Minimum Valid data range

IS-A 0.01 -999999.99 to +999999.99

IS-B 0.001 -999999.999 to +999999.999

IS-C 0.0001 -99999.9999 to +99999.9999

IS-D 0.00001 -9999.99999 to +9999.99999

deg.

IS-E 0.000001 -999.999999 to +999.999999

IS-A 0.001 -99999.999 to +99999.999

IS-B 0.0001 -99999.9999 to +99999.9999

IS-C 0.00001 -9999.99999 to +9999.99999

IS-D 0.000001 -999.999999 to +999.999999

inch

IS-E 0.0000001 -99.9999999 to +99.9999999

(B) Length and angle parameters (type 2)

Unit of data

Increment

system

Minimum

data unit

Valid data range

IS-A 0.01 0.00 to +999999.99

IS-B 0.001 0.000 to +999999.999

IS-C 0.0001 0.0000 to +99999.9999

IS-D 0.00001 0.00000 to +9999.99999

deg.

IS-E 0.000001 0.000000 to +999.999999

IS-A 0.001 0.000 to +99999.999

IS-B 0.0001 0.0000 to +99999.9999

IS-C 0.00001 0.00000 to +9999.99999

IS-D 0.000001 0.000000 to +999.999999

inch

IS-E 0.0000001 0.0000000 to +99.9999999
