Laser C 1000iA Maintenance manual Page 100

Maintenance manual
B-70255EN/01 6.TROUBLESHOOTING
- 93 -
6.6 INDICATION OF STATE BY MEANS OF SELF DIAGNOSTIC
FUNCTION
When the machine breaks down, it is necessary to know if the trouble
is in the CNC, PMC, machine or laser. Even when there does not exist
machine failure, the machine might hang-up for waiting of external
signals. Then the check of inside state of CNC, interface between
CNC and PMC, one between laser and CNC needs to be done. Here
the description is given on the indication of troubles taking place in
laser using the self-diagnostic function of CNC. The indication of
troubles in CNC, PMC as well as machine is described in the
maintenance manual.
FANUC Series 16i/160i-LA Maintenance Manual : B-63195EN
6.6.1 Data Items Displayed on the Diagnosis Screen
When the diagnosis function is used, the data indicated below can be
displayed.
CNC¬
¬¬
¬PMC status display
#7 #6 #5 #4 #3 #2 #1 #0
G220 *DU16 *DU8 *DU4 *DU2 *DU1
*DU1 to *DU16 Duty override signal (input)
#7 #6 #5 #4 #3 #2 #1 #0
G221 AGRDY CLRDY
AGRDY Assist gas prepared signal
CLRDY Chiller prepared signal
#7 #6 #5 #4 #3 #2 #1 #0
G222 HVON RUN AGST BEMON SHTON SCLON *BEMLC *SHTLC
HVON Discharge start signal
RUN Gas pressure control start signal
AGST Assist gas start signal
BEMON Beam on signal
SHTON Shutter open signal
SCLON Guide light on signal
*BEMLC Beam lock signal
*SHTLC Shutter lock signal
#7 #6 #5 #4 #3 #2 #1 #0
G223 POV7 POV6 POV5 POV4 POV3 POV2 POV1 POV0
POV7 to POV0 Power override signal
