Laser C 1000iA Maintenance manual Page 262

Maintenance manual
E.CONTROL SEQUENCES IN LASER OSCILLATOR APPENDIX B-70255EN/01
- 256 -
calibration, laser enters immediately oscillation preparation
completion (LSTR) state.
Check command :
When compensation is to be performed, the value set in PRM 15200
or PRM 15201 (output at compensation) Power ON is specified.
Then, by using the output monitor value obtained when the time set in
PRM 15205 has elapsed after the specification, the value of PRM
15204 (compensation coefficient) is found from the following
formula:
PRM.No.15204 = Pc(power command)/Pa(real power)´1024
Example）Pc = 2000W,Pa = 1900W
PRM.No.15204 = 2000/1900´1024 = 1077
The result is compared with PRM15203 (power calibration limit).
When PRM15204 exceeds PRM15203, the former is clamped by the
latter.
LSTR = ON : Oscillation preparation completion signal is on.
At this time, beam output from the laser oscillator becomes possible.
