6.TROUBLESHOOTING B-70255EN/01

- 70 -

Cause of trouble Solution

4 Anomaly in temperature sensor The temperature sensor is designed to

be actuated by temperatures of 60°C or

above. If the temperature sensor is

actuated at lower temperatures, replace

the sensor.

ALM No.4075

Condensation

A condensation sensor is mounted near the output mirror holder

in the oscillator. This alarm occurs when the sensor detects

condensation. After this alarm occurs, the alarm status cannot be

reset until the condensation status is released. Do not blow hot

air of 60

°C or higher on the condensation sensor.

Alarm output condition

This alarm is issued when the chiller water temperature signal becomes 0

during the time from RUN-ON until RUN-OFF.

Chiller water temperature signal

WT1 (bit 2 at address 01H of DI of the laser interface)

Related parameters

DGN.961#2 *WT1 Condensation sensor

Cause of trouble Solution

1 Tool low cooling water

temperature

Set the water temperature near the room

temperature (plus about 1°C).

2 Connecting anomaly of

condensation sensor cable

Check whether the cable is securely

connected to the condensation sensor. If

not, reattach the cable.

3 Anomaly of condensation

sensor

If the sensor operates when there is no

condensation around the sensor, the sensor

is abnormal. Replace the sensor.

ALM No.4076

Laser output decrease

This alarm is issued, if the monitored laser output is much lower

than the specified laser output, that is the monitored laser output

is lower than the specified output by a value specified in

parameter No. 15271.

Alarm output condition

This alarm is issued when the actual laser output level is lower than the

average command power (power x duty) by more than the value set in

parameter No. 15271. Monitoring, however, is not performed for three

seconds after the beam is turned or after the output is changed.

Related parameters

PRM.15271 Allowable output drop value

DGN.906 Actual output
