Laser C 1000iA Maintenance manual Page 130

Maintenance manual
B-70255EN/01 9.SETTING AND ADJUSTMENT
- 123 -
9.3 HIGH-FREQUENCY INVERTER
Connection
The following cables are connected to the inverter:
R, S, T : Main power input
U, V, W Inverter output
G : Grounding
1 : Reset signal
2 : Soft lock signal
8 : Inversion command signal
AL0, AL1 : Relay contact output (ON : Normal)
L : Analog power supply common
CM1 : Power supply common for the interface
CM2 : Common for the intelligent output terminal
Checking the parameters
The parameters of an inverter purchased by FANUC are set before shipment
from the factory. So, usually, the parameters need not be changed. The old
inverter can be replaced with a new one by reconnecting the cables, and the
new inverter can be used without any particular setting.
With the digital operator's panel attached to the inverter, all
parameters can be set and checked. Operate the digital operator's
panel with the power to the oscillator turned on.
Note, however, that no parameter can be modified when a cable is
connected to terminal 2 of the inverter control circuit.
When a parameter needs to be modified for a reason, detach the cable
connected to terminal 2 of the control circuit.
