Laser C 1000iA Maintenance manual Page 140

Maintenance manual
B-70255EN/01 9.SETTING AND ADJUSTMENT
- 133 -
9.4 GAS CONTROLLER
This unit is precisely adjusted at the factory and should not require
any further adjustment. If the intake unit, exhaust unit, or atmospheric
pressure unit is replaced or requires re-adjustment, however, it should
be set and adjusted as described below:
9.4.1 Setting the Gas Supply Pressure Sensor
The gas supply pressure sensor is the sensor marked with PSW1 on
the gas controller.
(1) Turn the CNC on. Never turn on the gas pressure control start
signal (RUN) at this stage.
(2) Set the secondary pressure of the regulator of the external laser
gas supply (gas cylinder, for example) to 0.1 MPa.
(3) Release the lock mode, then set desired values according to
Section 9.5. After setting, check that the LED (green) of OUT1
is on.
(4) To check the setting, reduce the secondary pressure of the
regulator on the laser gas supply unit (gas cylinder, for example)
to 0.04 MPa. The green LED of the gas supply pressure sensor
(OUT1) should go off.
(5) This completes the setting. Set the lock mode.
9.4.2 Setting the Atmospheric Pressure Sensor
NOTE
While setting the sensor, the gas controller is open to
the atmosphere. To prevent dust from entering the
controller, pay particular attention to the immediate
surroundings.
The atmospheric pressure sensor is the sensor marked with PSW2 on
the gas controller.
(1) Close the main circuit breaker and turn on the power supply,
then turn on the CNC. A voltage is supplied to the sensor. Never
turn on the gas pressure control start signal (RUN).
(2) Release the lock mode, then set desired values according to
Section 9.5.
