B-70255EN/01 6.TROUBLESHOOTING

- 77 -

Cause of trouble Solution

1 Contamination of shutter mirror Clean the shutter mirror. If this alarm

recurs after the shutter mirror is

cleaned, replace the mirror.

2 Anomaly of temperature sensor Replace the temperature sensor.

3 Temperature sensor cable

broken

Replace the cable.

4 Relay PCB (A16B-1600-0361) or

IF PCB(A16B-2100-0141) is

faulty.

Replace the faulty PCB.

5 Anomaly of PCB connection

cables

Check the connection of each cable.

ALM No.4088

Discharge tube voltage drop

This alarm is issued, if the voltage applied to the discharge tube

drops largely. More specific, the discharge tube voltage for

reference discharge is set up automatically to parameter No.

15270 each time the RUN button is pressed. This alarm is issued,

if the automatically set discharge tube voltage is lower than the

discharge voltage specified at the previous RUN time, by at least

the amount specified in parameter No. 15272.

Alarm output condition

During beam output, this alarm is issued when the actual laser output is in

one of the following conditions:

(1) Immediately before LSTR, the RF voltage of the power supply of the

discharge tube having the smallest number among the selected

discharge tubes is compared with the parameter setting (parameter No.

15270 to 15272). If the discharge tube voltage is lower than the

parameter setting, this alarm is issued. If the discharge tube voltage is

not lower than the parameter setting, the discharge tube voltage is set in

parameter No. 15270.

(2) When external power control is not performed during power

compensation or during LSTR, the discharge tube voltage is compared

with parameter setting (parameter No. 15270 to 15272). If the discharge

tube voltage is once lower than the parameter setting, a comparison is

made again 1024 msec later. If the second comparison also shows that

the discharge tube voltage is lower than the parameter setting, this

alarm is issued.

Related parameters

DGN.909-924 Discharge tube voltage and current

PRM.15270 Discharge tube voltage in normal condition

PRM.15271 Allowable discharge tube voltage drop

Cause of trouble Solution

1 The laser gas

composition is not

as specified.

Replace the laser gas with the specified one, that is

:He = 5:55:40% (volume ratio) with a

composition ratio accuracy of ±5%.

2 Anomaly of

discharge tube

voltage detection

system

If discharge is performed, but the monitored

discharge tube voltage is extremely low, replace the

matching box.

3 Degradation of Check whether the turbo blower and high-frequency
