4.INSTALLATION B-70255EN/01

- 32 -

4.2 PREPARATION PRIOR TO SHIPMENT

For shipment and transportation, follow the steps explained below.

(1) Disconnect all CNC connecting cables.

(2) Disconnect the power cable and ground cable.

(3) Remove the laser gas pipes, and attach blanking plugs to the

pipes to prevent dust from entering.

(4) When shipping the oscillator or exhaust pump only, follow the

steps explained below. If the oscillator and exhaust pump are

mounted on the machine, and so the possibility that the exhaust

pump may tumble does not exist, these steps are unnecessary.

(a) Detach the exhaust pump power line.

(b) Detach the gas piping from the exhaust pump, and plug up

the piping and exhaust pump to prevent foreign matter from

entering the piping and pump.

from the exhaust pump. When installing the exhaust pump,

supply new oil.

(5) Remove all cooling water from the oscillator by using

compressed air. For details of how to remove the cooling water,

see Subsection 4.2.2.

CAUTION

Any residual cooling water may result in corrosion or

clogging; furthermore, if any residual cooling water

freezes, a pipe or the oscillator itself may be

damaged.

(6) Install all clamps and fit a blanking cap onto the beam outlet.

(7) Check the security of all connectors and printed circuit boards.

Install protective covers.

(8) Check that all removed mounting screws are reinstalled.

(9) Install the cabinet mounting panel.
