Laser C 1000iA Maintenance manual Page 80

Maintenance manual
B-70255EN/01 6.TROUBLESHOOTING
- 73 -
ALM No.4080
Leakage of gas tube/anomaly of exhaust pump
When the RUN (pressure control start) button is pressed, the
exhaust pump starts evacuating the gas in the circulating system
to place the oscillator in the low-pressure state. This alarm
occurs when the pressure does not reach the exhaust completion
pressure specified for parameter No. 15240 until the specified
time (default: 10 minutes) has elapsed after the start of exhaust.
Alarm output condition
After RUN-ON, evacuation starts. When the laser gas pressure does not
reach the level set in parameter No. 15240 within the time set in parameter
No. 15259 after the start of evacuation, this alarm is issued.
Related parameters
PRM.15240 Evacuation completion negative pressure
Cause of trouble Solution
1 Incorrect gas pressure
control parameter setting
Check if the value of PRM No. 15240 is set as
indicated in the attached data sheets. If a
different value is set, set the value specified in
the data sheets.
2 Anomaly of IF PCB
(A16B-2100-0141)
If the gas pressure of the gas circulating system
does not decrease at all, the IF PCB may be
faulty. Check whether the CP89(Solenoid valve
signal) connector on the PCB is loose. Also
check the signals of the IF PCB. If an abnormal
signal is detected, replace the IF PCB.
3 Gas leakage from piping 1)Check whether any component joints in the
gas circulating system are loose. If a loose
joint is found, tighten the joint firmly.
2)Check whether any components in the gas
circulating system are cracked. If a cracked
component is found, replace that component.
3)Check whether the O-ring of each discharge
tube is worn. Replace any O-rings that exhibit
excessive wear. If a Teflon O-ring is ever
removed, it must be replaced with a new one.
4)Check whether there is a hole or crack in a
discharge tube. If a hole is found in a
discharge tube, replace the discharge tube.
4 Anomaly of exhaust
pump
Check whether the piping between the oscillator
and exhaust pump is normal.
