0i/0i Mate - Model C Maintenance manual Page 538

Maintenance manual
APPENDIXA. ALARM LIST
B–64115EN/01
514
Number ContentsMessage
101 PLEASE CLEAR MEMORY The power turned off while rewriting the memory by program edit opera-
tion. If this alarm has occurred, press <RESET> while pressing
<PROG>, and only the program being edited will be deleted.
Register the deleted program.
109 FORMAT ERROR IN G08 A value other than 0 or 1 was specified after P in the G08 code, or no
value was specified.
110 DATA OVERFLOW The absolute value of fixed decimal point display data exceeds the al-
lowable range. Modify the program.
111 CALCULATED DATA OVERFLOW The result of calculation turns out to be invalid, an alarm No.111 is is-
sued.
–10
47
to –10
–29
, 0, 10
–29
to 10
47
Modify the program.
112 DIVIDED BY ZERO Division by zero was specified. (including tan 90°)
Modify the program.
113 IMPROPER COMMAND A function which cannot be used in custom macro is commanded.
Modify the program.
114 FORMAT ERROR IN MACRO There is an error in other formats than <Formula>.
Modify the program.
115 ILLEGAL VARIABLE NUMBER A value not defined as a variable number is designated in the custom
macro or in high–speed cycle machining.
The header contents are improper. This alarm is given in the following
cases:
High speed cycle machining
1. The header corresponding to the specified machining cycle number
called is not found.
2. The cycle connection data value is out of the allowable range
(0 – 999).
3. The number of data in the header is out of the allowable range
(0 – 32767).
4. The start data variable number of executable format data is out of
the allowable range (#20000 – #85535).
5. The last storing data variable number of executable format data is
out of the allowable range (#85535).
6. The storing start data variable number of executable format data is
overlapped with the variable number used in the header.
Modify the program.
116 WRITE PROTECTED VARIABLE The left side of substitution statement is a variable whose substitution
is inhibited. Modify the program.
118 PARENTHESIS NESTING ERROR The nesting of bracket exceeds the upper limit (quintuple).
Modify the program.
119 ILLEGAL ARGUMENT The SQRT argument is negative. Or BCD argument is negative, and
other values than 0 to 9 are present on each line of BIN argument.
Modify the program.
122 FOUR FOLD MACRO MODAL–CALL The macro modal call is specified four fold.
Modify the program.
123 CAN NOT USE MACRO COMMAND
IN DNC
Macro control command is used during DNC operation.
Modify the program.
124 MISSING END STATEMENT DO – END does not correspond to 1 : 1. Modify the program.
125 FORMAT ERROR IN MACRO <Formula> format is erroneous. Modify the program.
126 ILLEGAL LOOP NUMBER In DOn, 1x n x3 is not established. Modify the program.
