0i/0i Mate - Model C Maintenance manual Page 650

Maintenance manual
E. FSSB START–UP PROCEDURE/
MATERIALS
B–64115EN/01
APPENDIX
626
(Amplifier setting)
No. AMP SERIES UNIT CUR. [AXIS] NAME
1 A1–L α SVM 40A [ 2 ] Y
2 A2–L α SVM 40A [ 1 ] X
3 A3–L α SVM 40A [ 4 ] A
4 A3–M α SVM 80A [ 3 ] Z
NO. EXTRA TYPE PCB ID
5 M1 A 0008 DETECTOR(4AXES)
>
MDI **** *** *** 13:11:56
[ AMP ][ AXIS ][ MAINT ][ ][ (OPRT) ]
Step 5 Press soft key [SETING]. (This soft key appears when a value
is entered.)
Step 6 Press function key
SYSTEM
.
Step 7 Pressing the continuous menu key
several times displays
[FSSB].
Step 8 Pressing soft key [FSSB] switches the screen display to the
amplifier setting screen, and displays the following soft keys:
[ AMP ][ AXIS ][ MAINT ][ ][ (OPRT) ]
Step 9 Press soft key [AXIS].
Step 10 Set the separate detector on the axis setting screen. (Separate
detector interface unit: M1/M2)
(AXIS SETTING)
AXIS NAME AMP M1 M2 1DSP Cs TNDM
1 X A2–L 0 0 0 0 0
2 Y A1–L 1 0 0 0 0
3 Z A3–M 0 0 0 0 0
4 A A3–L 2 0 0 0 0
>
MDI **** *** *** 13:11:56
[ AMP ][ AXIS ][ MAINT ][ ][ (OPRT) ]
Step 11 Press soft key [SETING]. (This soft key is displayed when a
value is entered.)
Step 12 Set bit 1 of parameter No. 1815 to 1 for the Y–axis and A–axis.
Step 13 Turn off then on the power to the CNC. This completes the
setting.
