APPENDIXA. ALARM LIST

B–64115EN/01

548

Alarm number ContentsFaulty location/corrective action

ER98 ILLEGAL LASER CON-

NECTION

Modify the allocation of the I/O module. When an I/O device for a laser is used,

the allocation of the I/O module does not

match the actual I/O device configura-

tion.

ER99 X,Y96–127 ARE ALLO-

CATED

Modify the allocation of the I/O module. When an I/O device for a laser is used,

another I/O device is allocated to

X96–127/Y96–127.

X96–127/Y96–127 are used for I/O de-

vices for a laser, and cannot be used for

other devices.

WN02 OPERATE ADDRESS ER-

ROR

Modify the setting of the PMC system pa-

rameter, address of the operator’s panel

for Series 0.

The setting of the PMC system parame-

ter, address of the operator’s panel for

Series 0, is invalid.

WN03 ABORT NC–WINDOW/

EXIN

1) Check that the Ladder program is free

from problems and then restart the

Ladder program (by pressing the RUN

key).

2) Turn the CNC off and then back on.

The Ladder program was stopped during

communication between the CNC and

PMC.

Function instructions such as WINDR,

WINDW, EXIN, and DISPB may not be

executed normally.

WN05 PMC TYPE NO CONVER-

SION

Using an offline programmer, change the

sequence program to that for the correct

PMC type.

The setting of the type in the sequence

program differs from the actual type.

(Example: For the PMC–SB5, the Lad-

der program of the PMC–SA3/SA5 was

transferred.)

WN06 TASK STOPPED BY DE-

BUG FUNC

To restart a user task that has been

stopped, stop the sequence program and

then execute it again.

When a PMC C board is used, a user

task has been stopped due to a break by

a debug function.

WN07 LADDER SP ERROR

(STACK)

Modify the sequence program so that the

subprogram nesting level is eight or less.

For a subprogram call with the function

instruction CALL or CALLU, the nesting

level is too deep (exceeds 8).

WN17 NO OPTION (LANGUAGE) 1) Restore the backed up parameter

data.

2) Check the data sheet and re–input the

parameters.

3) Contact FANUC to specify a PMC C

program option of the necessary size.

When a PMC C board is used, no PMC

C program option is found.

WN18 ORIGIN ADDRESS ER-

ROR

1) On the PMC system parameter

screen, press [ORIGIN].

2) Set the PMC system parameter, LAN-

GUGE ORIGIN, to the address indi-

cated by the RC_CTLB_INIT in the

map file.

When a PMC C board is used, the PMC

system parameter, LANGUAGE ORIGIN,

is invalid.

WN19 GDT ERROR (BASE, LIM-

IT)

Modify the setting in the user–defined GDT

in the link control statement or build file.

When a PMC C board is used, the

BASELIMIT or ENTRY in the user–de-

fined GDT is invalid.

WN20 COMMON MEM. COUNT

OVER

Change the number of shared memories

to eight or less.

Modify the link control statement, build file,

or other source files for shared memories.

When a PMC C board is used, the num-

ber of shared memories exceeds eight.
