APPENDIX

B–64115EN/01

A. ALARM LIST

551

(2) Alarm messages (PMC–SA1)

Message Contents and solution

ALARM NOTHING Normal status

ER00 PROGRAM DATA

ERROR(ROM)

The sequence program in the ROM is not written correctly.

(solution) Please exchange ROM for the sequence program.

ER01 PROGRAM DATA

ERROR(RAM)

The sequence program in the debugging RAM is defective.

(solution) Please clear the debugging RAM and input LADDER again.

The debugging RAM is not installed though the RAM is selected.

(solution) Please install the debugging RAM or install ROM for sequence program

and select ROM with K17#3=0.

ER02 PROGRAM SIZE OVER The size of sequence program exceeds the maximum size of LADDER(PMC–SC

only).

(solution) Please change MAX LADDER AREA SIZE at the SYSPRM screen and

restart the system.

ER03 PROGRAM SIZE

ERROR(OPTION)

The size of sequence program exceeds the option specification size.

(solution) Please increase the option specification size.

Or, reduce the size of sequence program.

ER04 PMC TYPE UNMATCH The PMC model setting of the sequence program is not corresponding to an actual

model.

(solution) Please change the PMC model setting by the offline programmer.

ER05 PMC MODULE TYPE

ERROR

The module type of the PMC engine is not correct.

(solution) Please exchange the module of PMC engine for a correct one.

ER07 NO OPTION

(LADDER STEP)

There is no step number option of LADDER.

ER10 OPTION AREA NOTHING

(series name)

The management software for the PMC–SB has not been transferred.

(solution) The software installation is not consistent with the order. Contact FANUC.

ER11 OPTION AREA NOTHING

(series name)

The management software for the PMC C board has not been transferred.

(solution) The software installation is not consistent with the order. Contact FANUC.

ER12 OPTION AREA ERROR

(series name)

The series of the management software for the PMC–RB differs between BASIC and

OPTION.

(solution) Contact FANUC.

ER13 OPTION AREA ERROR

(series name)

The series of the management software for the PMC C board differs between BASIC

and OPTION.

(solution) Contact FANUC.

ER14 OPTION AREA VERSIION

ERROR (series name)

The edition of the management software for the PMC–RB differs between BASIC

and OPTION.

(solution) Contact FANUC.

ER15 OPTION AREA VERSIION

ERROR (series name)

The edition of the management software for the PMC C board differs between BASIC

and OPTION.

(solution) Contact FANUC.

ER16 RAM CHECK ERROR

(PROGRAM RAM)

The debugging RAM cannot be read/written normally.

(solution) Please exchange the debugging RAM.

ER17 PROGRAM PARITY The parity error occurred on ROM for sequence program or the debugging RAM.

(solution) ROM: The deterioration of ROM may be deteriorated

Please exchange ROM for the sequence program

RAM: Please edit the sequence program once on PMC

Still the error occurs, exchange the debugging RAM.
