B-63943EN/02 8.CONNECTION TO FANUC I/O Link
- 173 -
8.3 UNITS THAT CAN BE CONNECTED USING FANUC I/O
Link
Basically, the 30i series can be connected to any unit that has a
FANUC I/O Link slave interface. The following table lists general
units that can be connected to the Series 30i. Detailed descriptions of
each unit are given later in this section. For details of other units,
refer to the documentation provided with the unit.
General units that can be connected to the 30i series
Unit Description Reference
FANUC I/O Unit-
MODEL A
Modular I/O unit that supports a combination
of the input/output signals required by a power
magnetics circuit.
Connection
and
maintenance
manual
B-61813E
FANUC I/O Unit-
MODEL B
Distribution type I/O unit that supports a
combination of input/output signals required
by a power magnetics circuit.
Connection
and
maintenance
manual
B-62163E
Handy Machine operator's
panel
Compact handy operation panel, used for
operation on the machine side, that consists of
the manual pulse generator, emergency stop
switch, enable switch, display unit, and input
key.
Connection
Manual
B-63753EN
Connector panel I/O module Distribution type I/O unit that handles the
input/output signals required by
the power magnetics circuit; it has an interface
with a manual pulse generator.
Sec. 8.4
Operator's panel I/O module
(for matrix input)
Unit having an interface with a machine
operator's panel; it has an interface
with a manual pulse generator.
Sec. 8.5
Operator's panel I/O module Unit having an interface with a machine
operator's panel that handles the input/output
signals required by the power magnetics
circuit; it has an interface with a manual pulse
generator.
Sec. 8.6
Power magnetics panel I/O
module
Unit having an interface with a power
magnetics panel that handles the input/output
signals required by the power magnetics
circuit.
Sec. 8.6
FANUC I/O Link connection
unit
Unit connecting FANUC I/O Link masters to
enable the transfer of DI/DO signals
Sec.8.7
FANUC servo unit β series
(with I/O Link)
Unit connected with the CNC via the FANUC
I/O Link to control a servo motor
Sec.8.8
Standard machine
operator's panel
The appearance of this machine operator's
panel is consistent with that of the 30i series.
The panel can easily be customized.
Sec.8.9
