13.PANEL i B-63943EN/02

- 328 -

13.4.2 Power Supply Specification

Input power

(1) Specification

To use the PANEL i, prepare a power supply that satisfies the

requirements listed below:

Input power supply voltage

+24VDC±10%

Current capacity

10 A or more

* When a FANUC device such as the Handy File is connected

to the RS-232C port, the required current is one ampere

higher.

(2) Timing

No power on/off sequence between the PANEL i and the CNC to

which the PANEL i is connected is defined.

When the PANEL i is connected to the CNC via HSSB, the

rotary switch on the HSSB interface board in the CNC

determines whether they are started separately or started together.

Supply power

If an input power supply that satisfies the above specifications is

prepared, the PANEL i can supply power to peripheral devices as

listed below.

Check the amount of current drawn by each unit you want to use.

Voltage Equipment Max. Current

Keyboard, Mouse

PCI extension board

IDE/ATAPI device Max. 2000mA

USB device Max. 500mA/port

+5V

PCMCIA card

Total

4000mA

Max. 500mA

PCI extension board

+3.3V

PCMCIA card

Total 3000mA

Max. 1000mA

+12V

PCI extension board

IDE/ATAPI device

Total 2500mA

-12V PCI extension board Total 150mA

Power Consumption

About 64 W (12.1” type, 15.0” type)

About 58 W (10.4” type)

Above operating includes the following devices.

- Main unit of the personal computer, HDD Unit, FAN for HDD,

Full Keyboard, and Mouse.

Above operating does not include the following devices.

- PCMCIA Card, PCI Extension board, and Devices to connect by

Serial or Parallel Interface, USB device, and expansion

IDE/ATAPI device
