B-63943EN/02 11.CONNECTION FOR Series 300is/310is/320is

- 313 -

11.3.4.3 USB port (rear side)

This port is used to connect a USB keyboard or USB printer.

LCD-mounted type or display unit for

series CNC

PCR-E20MD

Reserve

USB_0

Reserve

USB_

Reserve

USB_-

Reserve

Reserve10

USB_5

USB

Relay connector

D+

D-

JD54

Reserve

NOTE

This connector is used also as a serial port. The

Reserve pins must be left open.

(i) Connection example (conversion to a USB connector (type A,

receptacle])

NOTE

1 Commercially available USB devices are prone to compatibility problems with USB

hosts to some degree. It is not guaranteed that every commercially available USB

device can operate properly with USB hosts. Machine tool builders are requested

to check the operability of the USB devices they select. Keep in mind that

commercially available USB devices are generally neither dust-proof nor

moisture-resistant.

2 Generally, USB devices can be connected with the power kept on (hot plugging).

With this connector (JD54), however, hot plugging cannot be performed. By using

a USB connector (type A, receptacle) as a relay connector, hot plugging becomes

possible in the outer range from the USB relay connector.

3 The maximum USB power supply (USB_5V) current on the front and rear sides is

500 mA in total.

USB connector

USB_

USB_0

USB_5

D+

D-

Shield

JD54

Recommended cable specification:

Use a USB complient cable.

Recommended connector and housing (JD54 side):

Connector Housing Manufacturer

PCR-E20FA PCR-V20LA Honda

Tsushin

Kogyo

FI30-20S FI-20-CV2

FI-20-CV7

Hirose

Electric

FCN-247J020-G/E FCN-240C020-Y/S Fujitsu

52622-2011 52624-2015 Molex Japan
