30i/300i/300is-A, 31i/310i/310is-A & A5, 32i/320i/320is-A Connection manual (Hardware) Page 20

Connection manual (Hardware)
1.CONFIGURATION B-63943EN/02
- 2 -
1.1 CONTROL UNIT CONFIGURATION AND COMPONENT
NAMES
The 30i series control units are divided into two types: the
LCD-mounted type and stand-alone type.
LCD-mounted type control units have a built-in display. Stand-alone
type control units have a separate display unit. In the following
sections, the LCD-mounted type is also referred to as the
LCD-mounted type, and the stand-alone type is also referred to as the
stand-alone type.
The configuration and component names of each type are shown in
the figures given below. This manual explains how to attach the
connectors shown in these figures to devices. The numbers in
parentheses () in the figures are keyed to the item numbers of the
descriptions in this manual. The numbers in brackets [] in the figures
are connector numbers.
1.1.1 Configurations of LCD-mounted Type Control Units
LCD-mounted type Series 30i/31i/32i control units (A circle indicates
that the corresponding unit is available.)
Display unit Expansion slot Horizontal soft key Vertical soft key
30i 31i 32i
None 5+2 None
7.2"STN monochrome LCD
2 5+2 None
None 5+2 None
8.4"TFT color LCD
2 5+2 None
None 10+2 8+1
10.4"TFT color LCD
2 10+2 8+1
None 10+2 8+1
10.4"TFT color LCD
(with touch panel)
2 10+2 8+1
None 10+2 8+1
15"TFT color LCD
2 10+2 8+1
None 10+2 8+1
15"TFT color LCD
(with touch panel)
2 10+2 8+1
LCD-mounted type Series 300is/310is/320is control units (A circle
indicates that the corresponding unit is available.)
Display unit Expansion slot
Horizontal soft
key
Vertical soft
key
300is 310is 320is
None 10+2 8+1
10.4"TFT color LCD
2 10+2 8+1
None 10+2 8+1
10.4"TFT color LCD
(with touch panel)
2 10+2 8+1
None 10+2 8+1
12.1"TFT color LCD
2 10+2 8+1
None 10+2 8+1
12.1"TFT color LCD
(with touch panel)
2 10+2 8+1
None 10+2 8+1
15"TFT color LCD
2 10+2 8+1
None 10+2 8+1
15"TFT color LCD
(with touch panel)
2 10+2 8+1
