3.INSTALLATION B-63943EN/02
- 28 -
In this case, the allowable total heat dissipation for the cabinet is:
8 × 0.5722 × 13 + 3.7 × 0.2632 × 13 = 72 W.
In consequence, it can be concluded that the units shown in Table
3.4.3 on the next page can be installed in this cabinet.
Table 3.4.3
LCD-mounted type control unit (10.4” LCD) 33W
Optional board (Fast data server board) 3W
Optional board (Additional axis board) 4W
Standard machine operator's panel 15W
120-mm square fan motor for air mixing 8W
Total heat dissipation of the above 63W
NOTE
The 15 W quoted for the standard machine
operator's panel represents an example heat
output value when half of all the input signals are
turned on. This value varies, depending on the
mechanical configuration.
