4.POWER SUPPLY CONNECTION B-63943EN/02

- 56 -

interface unit, stand-alone type LCD unit, control power supply of the

servo amplifier, and separate detector (such as a scale).

As for a PANEL i, no specific power-off sequence for the CNC

control unit is required.

CAUTION

When the PANEL i is used, the OS must be shut

down before the power to the control unit is turned

off. Be careful not to turn off the power while the

hard disk is being accessed or before the OS has

terminated; otherwise, the hardware contents may

be destroyed.

When the power is turned off or when the power is momentarily

disconnected, processing must be performed from the machine as

necessary, because motor control is disabled.

For example, when movement along a vertical axis is controlled, a

brake should be applied to prevent falling. Usually, the brake clamps

the motor when the servo is not activated or when the motor is not

turning. The clamp is released only when the motor is turning.

When servo axis control is disabled by power-off or momentary

power disconnection, the brake usually clamps the servo motor. In

this case, before the relay for clamping operates, the controlled axis

may fall. So, also consider whether the distance the axis is likely to

fall will cause a problem.

When the power is turned off:

Be sure to apply a brake for clamping before turning off the

power to CNC.

When the power fails:

If a power failure is detected, a brake must be applied

immediately. Select the power supply with a longer DC power

retention time after AC power-off, because the servo is

deactivated if the power to CNC is turned off.
