30i/300i/300is-A, 31i/310i/310is-A & A5, 32i/320i/320is-A Connection manual (Hardware) Page 466

Connection manual (Hardware)
B.20-PIN INTERFACE CONNECTORS AND CABLES APPENDIX B-63943EN/02
- 448 -
Composite 12-core cable
(a) Specifications
Item Unit Specifications
Product No. - A66L-0001-0286
Manufacturer - Oki Cable, Ltd.
Hitachi Electric Cable Co., Ltd.
SHINKO ELECTRIC INDUSTRIES
CO., LTD.
Rating - 80°C, 30V
Conductor,braid-shiel
ded wire,drain wire
- Strand wire of tinned annealed
copper (JIS C3152)
Insulator - Heat-resistant flame-retardant vinyl
Material
Sheath - Oilproof, heat-resistant,
flame-retardant vinyl
Number of wires (wire ons.) Cores 6 (1 to 6) 6 (three pairs)
(7 to 9)
Size mm
2
0.5 0.18
Structure Conductors/
mm
20/0.18 7/0.18
Conductor
Outside diameter mm 0.94 0.54
Standard thickness
(The minimum
thickness is at least
80% of the standard
thickness.)
mm 0.25 0.2
Insulator
Outside diameter mm 1.50 0.94
Outside diameter mm 1.88
Direction of lay - Left
Twisted pair
Pitch mm 20 or less
Lay - Twist the wires at an appropriate
pitch so the outermost layer is
right-twisted, and wrap tape around
the outermost layer. Apply a cable
separator as required.
Lay diameter (approx.) mm 5.7
Size mm
2
0.3
Structure Wires/mm 12/0.18
Drain wire
Outside diameter mm 0.72
Element wire
diameter
mm 0.12
Thickness mm 0.3
Braid density % 70
Shield braid
Outside diameter mm 6.3
Color - Black
Standard thickness
(The minimum
thickness is at least
85% of the standard
thickness.)
mm 1.1
Sheath
Outside diameter mm 8.5Max. 9.0 (Note)
Standard length m 100
Packing method - Bundle
