8.4.11 Analog Input Connector Pin Allocation
This section describes the analog input connector pin allocation of
expansion module D.
NOTE
1 The DI/DO addresses of an expansion module and
the DI/DO addresses of the basic module are
contiguous. Addresses allocated to I/O Link are
handled as a group covering the basic and
expansion modules. That is, when the first
addresses allocated are X0004 and Y0000 (m = 4, n
= 0), the DI/DO addresses are as listed below.
2 When the analog input module, the DO space is also
used as an input channel selection area.
DI DO
Basic module
X4 to X6 Y0 to Y1
Expansion module 1
X7 to X9 Y2 to Y3
Expansion module 2
X10 to X12 Y4 to Y5
Expansion module 3
X13 to X15 Y6 to Y7
