B-63943EN/02 8.CONNECTION TO FANUC I/O Link

- 229 -

NOTE

1 Xm+0.0 through Xm+0.7 and Xm+5.0 through

Xm+5.7 are DI pins for which a common voltage

can be selected. That is, by connecting the

DICOM0 CE56(A14) or DICOM5 CE57(B14) pin to

the +24 V power supply, a DI signal can be input

with its logical state reversed. If, however, a cable

is connected to ground, it has the same effect as

inputting an ON state DI signal. To prevent this

from occurring, the connection of the DICOM0

CE56(A14) and DICOM5 CE57(B14) pins to the 0

V power supply is recommended whereever

possible.

For safety reasons, the emergency stop signal

needs to be allocated to an appropriate bit of the

addresses for which the common voltage is fixed.

See "Address allocation" in Section 8.6.9 for details

of how to allocate the emergency stop signal.

For unused DI pins allocated to the addresses for

which the common voltage is fixed, the logic is

fixed to "0". For unused pins allocated to the

addresses for which the common voltage can be

selected, the logic is fixed to "0" when the DICOM0

CE56(A14) or DICOM5 CE57(B14) pin is

connected to the 0 V power supply. When the

DICOM0 CE56(A14) or DICOM5 CE57(B14) pin is

connected to the +24 V power supply, the logic is

fixed to "1". The logic of the unused pins is

variable when the contacts of the DICOM0

CE56(A14) and DICOM5 CE57(B14) pins are

open.

2 An output DC voltage of +24 V at CE56 (B01) and

CE57 (B01) is for DI signals. Do not supply 24

VDC to these pins from the outside.
