30i/300i/300is-A, 31i/310i/310is-A & A5, 32i/320i/320is-A Connection manual (Hardware) Page 342

Connection manual (Hardware)
13.PANEL i B-63943EN/02
- 324 -
13.1 OVERVIEW
The PANEL i is on an IBM PC compatible panel computer.
Connecting the PANEL i to an i series CNC system via a high-speed
optical fiber (high-speed serial bus) provides the system with personal
computer functions.
13.2 CAUTIONS
• The copyright of Windows
XP, Windows
2000 and other
software provided with the PANEL i is owned by Microsoft
Corporation (USA), Intel Inc., Phoenix Technologies Ltd., and
FANUC LTD.
• No part of the software described above, or its manuals, may be
used or reproduced without permission.
• No part of the software described above, or its manuals, may be
sold independently of the PANEL i.
• The software described above, and its manual, must be used
under the conditions described in the attached license agreement.
• The use of the CNC incorporating the PANEL i shall imply that
the user agrees to the conditions of the license agreement
described above.
* Windows
XP and Windows
2000 is a registered trademark of
Microsoft corporation, USA
* Company name and product name mentions in this manual are
(registered) trademark of each company.
CAUTION
1 If an operation error or mishap occurs, the data on
the hard disk may be lost, even if all the installation
conditions are satisfied. Therefore, always
maintain a backup copy of the data on the hard
disk in case the stored data is lost or damaged.
Especially, the power-off on accessing the hard
disk must not be done because that possibility is
very high. Please concern for the end-users.
2 Be sure to finish the OS and the applications
through the proper operation of shutdown before
turning the power off.
Without the above-mentioned operation, there is
no assurance of the following action. At worst,
the command of initializing the HDD will not work.
