13.PANEL i B-63943EN/02

- 358 -

13.7 Punch Panel for PANEL i

13.7.1 Overview

The connector interfaces for personal computer functions such as

serial ports and parallel ports the PANEL i has are located on the rear

side of the PANEL i (the rear of the LCD unit). Once the PANEL i

has been installed in the machine, it is not easy to attach and detach

cables. The punch panel option allows the connector interfaces for

the personal computer functions to be used easily.

13.7.2 Specifications

Name Specifications (ordering number)

Independent type punch panel A08B-0082-C200

FA full keyboard with built-in punch

panel for 15” LCD (English)

A08B-0082-C151#EC

FA full keyboard with built-in punch

panel for 15” LCD (Japanese)

A08B-0082-C151#JC

Connection cable (for serial/USB

interface)

A08B-0082-K810

Connection cable (for parallel

interface)

A08B-0082-K811

Punch

panel for

PANEL i

Connection cable (for

keyboard/mouse interface)

A08B-0082-K812
