B-63943EN/02 8.CONNECTION TO FANUC I/O Link

- 189 -

8.4.13 Analog Input Signal Specifications

This section describes the specifications of the analog input signals

used with expansion module D.

Item Specifications Remarks

Number of input

channels (Note)

Four channels

Analog input DC -10 to +10 V

(Input resistance: 4.7 MΩ)

DC -20 to +20 mA

(Input resistance: 250 Ω)

Voltage input or

current input can be

selected on

channel-by-channel

basis.

Digital output

(Note)

12 bits (binary) Represented as

two's complement

Input/output

correspondence

Analog input Digital output

+10V +2000

+5V or +20mA +1000

0V or 0mA 0

-5V or -20mA -1000

-10V -2000

Resolution 5 mV or 20 µA

Overall precision Voltage input: ±0.5%

Current input: ±1%

With respect to full

scale

Maximum input

voltage/current

±15V/±30mA

Minimum

conversion time

(Note)

Ladder scan period of CNC

connected

Number of

occupied

input/output points

(Note)

DI = 3 bytes, DO = 2 bytes

NOTE

This analog input module has four input channels.

The digital output section consists of a group of 12

bits within the three-byte occupied input points.

This means that the channel to be used can be

dynamically selected by the ladder. The channel

switching DO point for channel selection is included

in the two-byte occupied output points.
