8.CONNECTION TO FANUC I/O Link B-63943EN/02

- 218 -

DI (input signal) specifications

(General-purpose input signal)

Contact rating

30 VDC, 16 mA or more

Open circuit intercontact

leakage current

1 mA or less (at 26.4 V)

Closed circuit

intercontact voltage drop

2 V or less (including cable voltage drop)

Delay

Receiver delay: Max. 2 ms

The time required for I/O Link transmission

between the CNC and I/O module (max. 2 ms

+ CNC ladder scan cycle) must also be taken

into account.

(Matrix input signal)

Contact rating

6 VDC, 2 mA or more

Open circuit intercontact

leakage current

0.2 mA or less (at 26 V)

Closed circuit

intercontact voltage drop

0.9 V or less (with a current of 1 mA)

Delay

The maximum matrix period of 16 ms, the

maximum time of I/O Link transfer between

CNC and I/O module of 2 ms, and the ladder

scanning period (by CNC) must be

considered.

NOTE

When detour prevention diodes are used, the

voltage drop across closed contacts indicated

above must be maintained, including the diode

voltage drop.

DO (output signal) specifications

Maximum load current in

ON state

200 mA or less (including momentary current)

Saturation voltage in ON

state

Max. 1 V (when load current is 200 mA)

Withstand voltage

24 V +20% or less (including momentary

values)

Leakage current in OFF

state

20 µA or less

Delay

Driver delay: Max. 50 µs

The time required for I/O Link transmission

between the CNC and I/O module (max. 2 ms

+ CNC ladder scan cycle) must also be taken

into account.

NOTE

Ensure that the maximum current per DOCOM pin

(DO power supply pin) does not exceed 0.7 A.
