B-63943EN/02 3.INSTALLATION

- 21 -

3.2 POWER SUPPLY CAPACITY

3.2.1 Power Supply Capacities of CNC-related Units

The following CNC-related units require an input power supply that

satisfies the indicated current capacities with a power supply voltage

of 24 VDC ±10%. Here, note that momentary voltage changes and

ripples are also within ±10% of the power supply voltage.

Table 3.2.1 (a) Power supply capacity

Unit

Power

supply

capacity

Remarks

7.2”/8.4”/10.4” type display unit

1.6A

Note 1) LCD-mounted

type control

unit

15” type display unit

2.2A

Note 1)

Control unit (alone)

1.6A

10.4” display unit

0.7A

Stand-alone

type control

unit

15” display unit

1.5A

Additional axis board

0.3A

Additional spindle board

0.2A

Fast data server board

0.2A

HSSB board

0.2A

Profibus master board

0.2A

Profibus slave board

0.1A

FL-net board

0.2A

Optional board

DeviceNet (master) board

0.1A

NOTE

1 The liquid-crystal display and MDI unit are

included. Optional boards are not included.

2 When an RS-232C unit (with power supplied from

the NC) is connected to the RS-232C port, +0.2 A

is further required.

3 Use memory cards that consume no more than 2

4 For the PANEL i, see Chapter 13.

5 For the FS300i/310is/320is, see Chapter 11.

6 For other peripheral units (such as I/O units), see

Table 3.2.1 (b) and also refer to the relevant

manuals.

7 When you select the input DC power supply for the

CNC control section, consider the restrictions other

than the power supply capacity. Be sure to see

also Subsection 4.4.2.
