30i/300i/300is-A, 31i/310i/310is-A & A5, 32i/320i/320is-A Connection manual (Hardware) Page 38

Connection manual (Hardware)
3.INSTALLATION B-63943EN/02
- 20 -
3.1.2 Installation Conditions of the CNC and Servo Unit in the
Cabinet
Condition
LCD-mounted type control unit
and display unit
Stand-alone type
control unit
Operating 0°C to 58°C 0°C to 55°C
Storage,
Transport
−20°C to 60°C
Ambient
temperature
Temperature
change
0.3°C/minute or less
Normal 75%RH or less, no condensation
Humidity
Short period
(less than 1
month)
95%RH or less, no condensation
Operating
0.5G or less
FANUC conducted an evaluation test under the
following conditions:
10 to 58 Hz: 0.075 mm (amplitude)
58 to 500Hz: 1G
Direction of vibration: Each of the X, Y, and Z directions
Number of sweep cycles: 10
Conforming to IEC68-2-6
Vibration
Non-operating 1.0G or less
Operating Up to 1000 m (Note in Subsection 3.1.1) Meters
above sea
level
Non-operating Up to 12000 m
Environment
Coolant, lubricant, or cutting chips shall not be sprinkled
directly over the CNC or servo unit. No corrosive gas
shall be allowed.
NOTE
If you want to use a PANEL i, see also Chapter 13.
