13.PANEL i B-63943EN/02

- 354 -

13.6.13 MDI

PANEL i

JA61

(

PCR-EV20MDT

)

MDI

CK1 or CK27

(PCR-E20MDK-SL-A)

1 *KEY00 11 *KEY01

2 *KEY02 12 *KEY03

3 *KEY04 13 *KEY05

4 *KEY06 14 *KEY07

5 *COM00 15 *COM01

6 *COM02 16 *COM03

7 *COM04 17 *COM05

8 *COM06 18 *COM07

9 *COM08 19 *COM09

10 *COM10 20 *COM11

1 *KEY00 11 *KEY01

2 *KEY02 12 *KEY03

3 *KEY04 13 *KEY05

4 *KEY06 14 *KEY07

5 *COM00 15 *COM01

6 *COM02 16 *COM03

7 *COM04 17 *COM05

8 *COM06 18 *COM07

9 *COM08 19 *COM09

10 *COM10 20 *COM11

(1) Specification of the recommended cable conductor

A66L-0001-0284#10P : 0.08mm

× 10 pairs

(2) Recommended connector for cable and housing

Connector Housing Manufacture

PCR-E20FA PCR-V20LA/PCS-E20LA Honda Tsushin

Kogyo

FI30-20S FI-20-CV2/FI-20-CV7 Hirose Electric

FCN-247J020-G/E FCN-240C020-Y/S Fujitsu

52622-2011 52624-2015 Molex Japan

(3) Notes

(a) The MDI unit cannot be used for BIOS setup for the

PANEL i. For BIOS setup, a keyboard connected to a

connector (CD32L) or USB connector is required.

(b) Input from the MDI unit is processed by the CNC via HSSB.

Therefore, to apply input from the MDI unit to the PANEL

- HSSB connection to the CNC must be established.

- On the PANEL i, the operating system must have been

loaded, and the MDI driver must have been operating.
