B-63943EN/02 11.CONNECTION FOR Series 300is/310is/320is

- 303 -

(b) Cable Wires

Many cables without a shield (UTP cables) are

commercially available as twisted pair cables conforming to

10BASE-T or 100BASE-TX. To improve noise immunity

in factory automation environments, however, be sure to use

twisted pair cables (STP cables) with a common shield in

category 5.

Recommended cables (for fixed parts)

Manufacturer Specification Remark

Furukawa Electric Co., Ltd. DTS5087C-4P Twisted wires

Nissei Electric Co., Ltd. F-4PFWMF Single-wire cable

NOTE

These recommended cables for fixed parts must

not be used for movable sections. Be sure to use

the following recommended cables for movable

sections.

Recommended cable (for movable sections)

Manufacturer Specification Remark

Oki Electric Cable AWG26 4P TPMC-C5-F(SB) Dedicated to FANUC

products

Cable specification (FANUC original product, with no connector)

Drawing number: A66L-0001-0453

Manufacturer: Oki Electric Cable Co., Ltd.

Specification

• Electrical characteristic:

Complying with EIA/TIA 568A categories 3

and 5

The length of the cable to the hub must be kept

within 50 m because of its attenuation

performance.

• Structure : Common-shield braided cable with drain wire

The conductors of the cable are AWG26

annealed-copper strand wire, with a sheath 0.8

mm thick and an outer diameter of 6.7±0.3 mm

• Fire resistance : UL1581 VW-1

• Oil resistance : As per FANUC's internal standard (Equivalent

to conventional oil-resistant electrical cable)

• Flex resistance : Million or more bending cycles with a bending

radius of 50 mm (U-shaped bend test)

• UL style No. : AWM20276 (80°C/30V/VW-1)

NOTE

Use the TM21CP-88P(03) connector made by

Hirose Electric Co., Ltd. to this cable.

About cable assemblies
