If any of G330 to G339 is specified, check the end code. The close
processing has no end code because the processing always terminates
normally.
#8539 Contents
0 Normal termination
1 The circuit is not open.
6 A necessary option is missing.
7 The card is write–protected.
8 A memory overflow occurred during downloading.
A block of G330 to G339 contains an illegal value (P, Q, R, etc.). Alterna-
tively, necessary data is not specified.
9 The data format is wrong.
10 A wrong file number is specified.
30 No memory card is inserted.
32 The battery power is low.
33 A memory overflow occurred during saving.
102 The memory card does not have a sufficient space.
114 The specified file cannot be found.
115 The specified file is protected.
An undefined variable number is specified.
117 The file is opened in a wrong mode.
119 The file is locked.
121 The file ends.
122 A wrong file name is specified.
124 A wrong file extension is specified.
129 The specified function is not supported.
140 The file attribute is read/write–disabled.
141 Close the file.
6.5.2.8
End Codes (#8539)
