1. Fanuc
  2. SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor

SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor Programming manual Page 25

Programming manual
B–61803E–1/10
2. MACRO COMPILER AND MACRO
EXECUTOR
PROGRAMMING
15
(4) On the Series 16/18-TTA, however, the following data transfer
selection screen is displayed instead of the above title.
Pressing address key M on the screen selects tool post 1 and pressing
address key S selects tool post 2.
Pressing numeric key 0 starts the Series 16/18-TTA and enables the
executor to execute the macros loaded in the RAM.
MACRO COMPILER/EXECUTOR P–CODE LOADER
(I/O PARAMETERS) (DATA TRANSFER)
I/O CHANNEL = 0 (MAPPING – 1MB)
I/O UNIT = 0
BAUDRATE =11
STOP BIT = 1
INPUT CODE = 1
LOADING PATH 1 : YES (PUSH M KEY)
LOADING PATH 2 : YES (PUSH S KEY)
LOADING END : YES (PUSH 0 KEY)
For the Series 16/18–TTA onty
(5) On CNCs other than the Series 16/18-TTA, performing the operation
in step (3) displays the following screen. On the Series 16/18-TTA,
selecting a tool post displays the following screen and initializes the
RAM.
The following screen remains displayed while the RAM is being
initialized. If the RAM has low capacity, the screen in step (6) may
be displayed instead of the following screen.
The selected tool post, HEAD 1 or HEAD 2, is displayed on the
second line of the screen for the Series 16/18-TTA.
MACRO COMPILER/EXECUTOR P–CODE LOADER
HEAD 1/HEAD 2
(I/O PARAMETERS) (DATA TRANSFER)
I/O CHANNEL = 0 (MAPPING – 1MB)
I/O UNIT = 0
BAUDRATE =11
STOP BIT = 1
INPUT CODE = 1
OMM RAM MODULE INITIALIZE
Screen for the Series 16/18-TTA
(The screens shown in subsequent
steps are for the same CNC
series.)
