APPENDIXO. FANUC Super CAPi T
564
(*7) Machining cycle
1 : Roughing 2 : Finishing 3 : Chamfering
This is set automatically when a new process is created. And, this is used for a distinction
between roughing, finishing, and chamfering and for arranging processes with ”Roughing
priority”.
(*8) Spindle gear
1 : Automatic 2 : Low speed 3 : Middle speed 1 4 : Middle speed 2
5 : High speed
(*9) Cutting speed/Spindle speed selection
0 (or #0) : Cutting speed 1 : Spindle speed
(*10) Grooving pattern
1 : Normal 2 : Slant 3 : Trapezoid 4 : Thread
5 : Unused 6 : Unused 7 : Unused 8 : Unused
9 : Option
(*11) Necking figure
1 : General 2 : Necking 1 for abrasion 3: Necking 2 for abrasion
4: Necking for threading
(*12) Automatic preceding process determination flag
1 : Process generated by automatic preceding process determination
0 (or #0) : Process generated by normal edit (MDI key input)
(When automatic preceding process determination is executed, the flag is set to 1 even for
the last process.)
(*13) Machining type (2)
< Center drilling / C–axis center drilling >
1 : Center 2 : Center + Chamfer 3 : Starting 4 : Starting + Chamfer
< Drilling >
1 : Drilling 2 : Reaming 3 : Boring 4 : End–milling
5 : Throwaway drilling
< C–axis drilling >
1 : Drilling 2 : Reaming 3 : Boring 4 : End–milling
(*14) Machining pattern
< Drilling / C–axis drilling >
1 : Hole drilling 2 : Hole pecking 3 : Hole hi–spd. pecking
4 : Penetrate drilling 5 : Penetrate pecking 6 : Penetrate hi–spd. pecking
< End–milling / C–axis end–milling >
1 : Residual cutting 2 : Spot facing
< Reaming / C–axis reaming >
1 : Hole 2 : Penetrate
(*15) Chamfering amount
When numerical values other than ”0” are input here, the chamfering process is made.
However, when the chamfering process has already existed, it is not this.
(*16) Open drawing
These areas are only used for showing open drawing on an animated drawing screen.
(*17) Groove diameter / Groove depth selection
(When machining area is face, groove depth is always selected.)
0 (or #0) : Groove depth 1 : Groove diameter
