<Command format>
G243 Xx Yy (“80qq”) ;
Xx, Yy: Specifies a display start position. X and Y represent an X coor-
dinate and Y coordinate in the character coordinate system,
respectively.
(“80qq”):Specifies the external character number of an external charac-
ter to be displayed. Note, however, that an external charac-
ter number from 00 to 39 must be specified for qq in hexade-
cimal. 80qq must be enclosed in quotation marks inside of
parentheses.
That is, 80qq must be specified in the format (”80qq”).)
qq: 00h to 27h in hexadecimal (external character
number from 00 to 39
Example: Command for displaying the external character (20th char-
acter in external character memory) registered in Example
(1) above
G243 X
Y “8014” ;
B–61803E–1/10
6. FUNCTIONS OF THE MACRO
EXECUTOR
PROGRAMMING
157
(2) Displaying external characters
By executing a G code in the format below, an external character
stored in external character memory can be displayed.
External character
number
Command value
(80qq)
00
01
02
·
·
·
10
11
12
13
14
15
16
17
·
·
·
·
·
·
38
39
8000
8001
8002
·
·
·
800A
800B
800C
800D
800E
800F
8010
8011
·
·
·
·
·
·
8026
8027
NOTE
Be sure to specify a hexadecimal value from 00h to 27h for
qq. Otherwise, the display function does not function
normally.)
