SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor Programming manual Page 399

Programming manual
B–61803E–1/10
APPENDIX
E. FANUC Super CAP T/CAP II T MACRO
COMPILER/EXECUTOR (Series 16/18)
and Super Capi T Macro Compiler/
EXECUTOR (Series 16i/18i/21iT)
389
Macro
variable
Corresponding
data
Processes in which
the variable can be
referred to
Description
#20631 The program to be called is a :
0 : User program stored in the NC program area
1 : P-code program
Sub-calling, transfer,
and auxiliary pro-
cesses
PRM No.9777
#1-#5
PRM No.9778
#0, #1
#20630 The tool post to be selected is :
0 : Head 1
1 : Head 2
All processes
#20629
#20628
#20627
#20626
#20625
#20624 Cutting allowance on the end face at head 2
[Length]–([cutting allowance on the end face]+
[length of the product])
If the result is negative, set this to 0.
All processes Initial setting
#20623 Compensation along the Z-axis for copying blanks
When the program origin is positioned on the end face of
a workpiece : A+B+C
When the program origin is positioned on the end face of
a chuck : A+B–C
Where,
A : Z coordinate of the center of the screen at head 1
B : Z coordinate of the center of the screen at head 2
C : Length of the product
#20622
#20621
#20620
#20619 Flag related to cutting on the end faces
0 : End facing is not performed in bar machining.
1 : End facing is also performed in bar machining.
Bar machining
#20618 The program to be called for switching turning to milling is a :
0 : User program stored in the NC program area
1 : P-code program
All processes PRM No.9778#3
#20617 The program to be called for switching milling to turning is a :
0 : User program stored in the NC program area
1 : P-code program
All processes PRM No.9778#4
#20616 Innermost diameter All processes Initial setting
#20615 M code for calling a sub-program All processes Compile PRM No.
9033
#20614 Destination for calling a T code
0 : NC program in the RAM
1 : P-code program in the ROM
All processes PRM No.9778#7
#20613 Sub-program calling by the end M code (P code)
0 : The end M code is output.
1 : The sub-program is called by the end M code.
All processes PRM No.9779#2
