SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor Programming manual Page 362

Programming manual

Page of 612

/ 612

B–61803E–1/10

APPENDIX

E. FANUC Super CAP T/CAP II T MACRO

COMPILER/EXECUTOR (Series 16/18)

and Super Capi T Macro Compiler/

EXECUTOR (Series 16i/18i/21iT)

352

D Transfer, Auxiliary Process

+ 0 Process number +30 Display data 10 (Data format)

+ 1 Unused +31 Display data 11

+ 2 System utilization area (∗3) +32 Display data 11 (Data format)

+ 3 Machining type (∗4) +33 Display data 12

+ 4 Unused +34 Display data 12 (Data format)

+ 5 Tool post (Spindle axis selection) (∗6, ∗21) +35

+ 6 Machining cycle (∗7, ∗21) +36

+ 7 Type +37

+ 8 Type (Data format) +38

+ 9 Head +39

+10 Head (Data format) +40

+11 Dispaly data 1 +41

+12 Dispaly data 1 (Data format) +42

+13 Display data 2 +43

+14 Display data 2 (Data format) +44

+15 Display data 3 +45

+16 Display data 3 (Data format) +46

+17 Display data 4 +47

+18 Display data 4 (Data format) +48 Run hour

+19 Display data 5 +49 Unused

+20 Display data 5 (Data format) +50 Surface speed/speed selection (∗9)

+21 Display data 6 +51 Speed

+22 Display data 6 (Data format) +52 * First variable number for roughing

+23 Display data 7 +53 * First variable number for finishing

+24 Display data 7 (Data format) +54 * First variable number for chamfering

+25 Display data 8 +55 * First variable number of a figure block

+26 Display data 8 (Data format) +56 * Unused

+27 Display data 9 +57 * Use status flag (0: Not used, 1: Used)

+28 Display data 9 (Data format) +58 * First variable number of the preceding process

+29 Display data 10 +59 * First variable number of the next process

F: Ver.2 or later, J: Ver.3 or later, (

?): See the note below.

NOTE

Some item names depend on the version.

* : System management area –

Avoid data writing by a user program.

If there are no processes corresponding to +52 to +59, or if the current

process corresponds to any of those processes, the area is set to null

or 0.

Data area for user programs

used with the macro executor
