  2. SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor

SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor Programming manual Page 522

Programming manual
B–61803E–1/10
APPENDIXO. FANUC Super CAPi T
512
0 : Data with decimal point
1–7: The number of digits below a decimal point
It is possible to output NC program to the format of the macro program
call.
D Setting output data to necessary variables
D Setting #0 to unnecessary variables
D Executing ”P8” or ”P9” command
”P8” in case of G–code call
”P9” in case of M–code call
NOTE
1 #107?? is P–code variable. The limits are #10700–#10742.
When P–code macro variables 4000 function is available,
the limits of variables are #14000–#14042.
And, when Complex lathe application is available, the limits
of variables for 2nd path are #10800–#10842 or #14100–
#14142.
2 In case setting data is #0, the corresponding address is not
output.
3 The data in variables of expanded P–code cannot be
rewritten. If they are rewritten, the system might not work
correctly.
O.1.3.3
Output condition
Previous page
Next page
