J. PARAMETERS
APPENDIX
471
#7 #6 #5 #4 #3 #2 #1 #0
8000 ROMM 16BT BAUD M30 M02 M99
(Exclusive for FANUC SYSTEM P-MODEL G)
M99 0 : M99 does not terminate compilation of a single program.
1 : M99 terminates compilation of a single program.
M02 0 : M02 does not terminate compilation of a single program.
1 : M02 terminates compilation of a single program.
M30 0 : M30 does not terminate compilation of a single program.
1 : M30 terminates compilation of a single program.
BAUD 0 : Data is transferred to the FA-WRITER at a baud rate of
4800 bps.
1 : Data is transferred to the FA-WRITER at a baud rate of
9600 bps.
16BT 0 : Data is written into the ROM module in units of 32 bits.
(For Series 16)
1 : Data is written into the ROM module in units of 16 bits.
(For Series 18)
ROMM 0 : The ROM cassette is used. (For Series 0)
1 : The ROM module is used. (For Series 16 or 18)
#7 #6 #5 #4 #3 #2 #1 #0
8010 CAP
(Exclusive for FANUC SYSTEM P-MODEL G)
CAP 0 : The macro executor has one file.
1 : The macro executor has two files. (Conversational type)
#7 #6 #5 #4 #3 #2 #1 #0
9000 LD6 R1M R512 R256 R128 VRFY
(Exclusive for FANUC SYSTEM P-MODEL G)
VRFY 0 : The ROM is not checked when the data is output to it.
1 : The ROM is checked when the data is output to it.
R128 0 : Data is output to the 64K-byte ROM cassette. (Only for
FS0)
1 : Data is output to the 128K-byte ROM cassette or module.
(Only for FS18/20-MA/21-TB)
R256 0 : R128 is referenced.
1 : Data is output to the 256K-byte ROM cassette or module.
R512 0 : R256 is referenced.
1 : Data is output to the 512K-byte ROM cassette or module.
R1M 0 : R512 is referenced.
1 : Data is output to the 1M-byte ROM cassette or module.
LD6 1 : Always specify 1.
NOTE
If both R512 and R256 are set to 1, the data is output to the
768K-byte ROM module.
J.1
COMPILE
PARAMERTES
