N. DISPLAY WITH A BACKGROUND COLOR
ON THE CUSTOM SCREEN
B–61803E–1/10
APPENDIX
506
Note the following related compile parameters for display.
#7 #6 #5 #4 #3 #2 #1 #0
9002 DAUX
DAUX = 0 : The CUSTOM screen is not displayed at power–up.
= 1 : The CUSTOM screen is displayed at power–up.
#7 #6 #5 #4 #3 #2 #1 #0
9003 HRGR ONMSK
ONMSK = 0 : The O and N numbers are displayed on the CUSTOM
screen.
= 1 : The O and N numbers are not displayed on the
CUSTOM screen.
HRGR = 0 : Graphic display is performed in standard mode.
= 1 : Graphic display is performed in high resolution mode
(only for a window displayed with seven soft keys).
#7 #6 #5 #4 #3 #2 #1 #0
9006 NNUM US19W DAUXR STDM
STDM = 0 : The mode or status is displayed on the CUSTOM
screen.
= 1 : The mode or status is not displayed on the CUSTOM
screen.
DAUXR = 0 : The CUSTOM screen is not displayed when the system
is in emergency stop status at power–up.
= 1 : The CUSTOM screen is displayed when the system is
in emergency stop status at power–up. (Set the DAUX
bit (bit 5 of parameter 9002) to 1 as well.)
US19W = 0 : When display with 12 soft keys is selected, the
CUSTOM screen (USER1) is not displayed as a
window with seven soft keys.
= 1 : When display with 12 soft keys is selected, the
CUSTOM screen (USER1) is displayed as a window
with seven soft keys.
NNUM = 0 : When data input control is valid for the CUSTOM
screen, the NUM prompt is displayed.
= 1 : When data input control is valid for the CUSTOM
screen, the NUM prompt is not displayed.
N.6
RELATED ITEMS
N.6.1
Related Compile
Parameters
