SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor Programming manual Page 468

Programming manual
G. DIFFERENCES BETWEEN
Series 0 AND Series 16/18/0i
(CONVERSION FROM FS0 TO FS16/18/0i)
B–61803E–1/10
APPENDIX
458
In FS0, a command such as #100=P100.2; can be specified. In FS16,
however, use a command such as #100=[P100 AND 4]/4; instead.
#7 #6 #5 #4 #3 #2 #1 #0
Compile parameter
9000 R3MB R2MB R1MB R512 R256
#6 (R3MB) Writes data in a 3M-byte ROM module.
#5 (R2MB) Writes data in a 2M-byte ROM module.
#4 (R1MB) Writes data in a 1M-byte ROM module.
#3 (R512) Writes data in a 512K-byte ROM module.
#2 (R256) Writes data in a 256K-byte ROM module.
NOTE
For Series 0i, a ROM module of up to 512K bytes can be specified.
G.9
A BIT CANNOT BE
SPECIFIED TO READ
A PARAMETER.
G.10
THE ROM SIZE IS
SPECIFIED
DIFFERENTLY.
