J. PARAMETERS
APPENDIX
473
#7 #6 #5 #4 #3 #2 #1 #0
9002 EXT1 PWSR DAUX XDIL EVF ACL2 ACL1 TCAL
TCAL 0 : Makes invalid the sub-program call with T code
1 : Makes effective the sub-program call with T code
ACL1 0 : Makes invalid call by the specific code
1 : Makes effective call by the specific code (O9004/#146)
ACL2 0 : Makes invalid call by the specific code
1 : Makes effective call by the specific code (O9005/#147)
EVF 0 : Extension P-CODE variable #20000 is the floating
decimal point format
1 : Extension P-CODE variable #20000 is the fixed decimal
format
XDIL 0 : Axis interlock function invalid
1 : Axis interlock function valid
DAUX 0 : Does not make the CUSTOM screen appear at power on
1 : Makes CUSTOM screen appear at power on
PWSR 0 : P CODE work number search function invalid
1 : P CODE work number search valid
EXT1 0: Extension functions invalid
1: Extension functions valid (RS-232-C control, NC program
access)
CAUTION
When EXT1 = 1, part program memory reduces by 1.63 m
in the following CNCs.
– Series 16/18 (Part program memory capacity is 80m or less.)
– Series 20 (Part program memory capacity is 80m or less.)
– Series 21–MB (In the D201 series, part program memory
capacity is 80m or less.)
– Series 21–TB (Control unit A)
#7 #6 #5 #4 #3 #2 #1 #0
9003 PTCR KY20 HRGR ONMSK
ONMSK 0 : The O and N numbers are displayed on the CUSTOM
screen.
1 : The O and N numbers are not displayed on the CUSTOM
screen.
HRGR 0 : Standard mode graphic display
1 : High resolution graphic mode display (set to “1” usually)
KY20 0 : Not +a to #8501 with decimal point input by key input
variables
1 : +a to #8501 with decimal input by key input variables
(+(: +20 for a display of seven soft key type)
(+(: +40 for a display of twelve soft key type)
PTCR 0 : Does not output ”CR” code twice in P-CODE variable
outputting
1 : Output ”CR” code twice in P-CODE variable outputting
