SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor Programming manual Page 107

Programming manual
B–61803E–1/10
6. FUNCTIONS OF THE MACRO
EXECUTOR
PROGRAMMING
97
#8521=3 ;
#8522=100 ;
G325 ;
IF[#8529 NE 0] GOTO900 ;
End of reading
N900 ;
Error
The following program data is loaded from #100 which is specified
by variable number #8522, when the above instruction is executed.;
#100=7 Address ”G”
#101=90 Number
#102=7 Address ”G”
#103=0 Number
#104=24 Address ”X”
#105=10.5 Number
#106=13 Address ”M”
#107=5 Numbew
#108=27 Address ”EOB”
EOR (28) is housed as an address, if EOB is not at the end block of
the program or EOR position is specified with block number.
Reading is not conducted as the end code becomes ”255”
, if a block
No. exceeding the block of EOR is specified.
(Example)
O0004 ;
G92 X0. M08 ;
M02
%
#100=13 Address ”M”
#101=2 Number
#102=28 Address ”EOR”
(Example)
If
O0004 ;
G92 X0. M08 ;
%
#100=28 Address ”EOR”
If the function for reading a specified block coded in words (G325)
reads a block which is not coded in words, completion code #8529 is
set to 253 to indicate the fact.
When the completion code is set to 253, use the function for reading
a specified block coded in characters (G328) to read the same block.
#8520 = program-number ;
#8521 = block-number ;
