1. Fanuc
  2. SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor

SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor Programming manual Page 275

Programming manual
B–61803E–1/10
E. FANUC Super CAP T/CAP II T MACRO
COMPILER/EXECUTOR (Series 16/18)
and Super Capi T Macro Compiler/
EXECUTOR (Series 16i/18i/21iT)
APPENDIX
265
NOTE
1
Whether a function can be used varies from version to version. For
details, see the relevant section of this manual.
2 The Series 20/21 does not support a macro compiler/executor with
Super CAP T.
3 The Series 20i does not include macro compilers/executors
attached with Super CAPiT.
4 Before the Super CAP T/II T and the Super CAPiT can be
operated for the first time, with the user programs created
by the machine tool builder and the FANUC–supplied
system programs being stored in the ROM module or flash
ROM of the Super CAP T/II T and the Super CAPiT and
placed in the mounted state, all programs must be erased
from the part program storage.
(For a one–path system, place the system in setting mode
(PWE = 1) and turn the power on while pressing and holding
down the [DELETE] key.
For a two–path system, place the system in two–path
setting mode (PWE = 1) and turn the power on while
pressing and holding down both the [DELETE] key and the
[1] numeric key. Then, turn the power off. Then, turn the
power on again while pressing and holding down the
[DELETE] key and the [2] numeric key.)
This operation causes all P–CODE variables to be initialized
to <null>.
If the part program storage already contains programs, it is
necessary to back up the programs and erase all the
programs from the part program storage before the user
programs created by the machine tool builder and the
FANUC–supplied system programs can be stored in the
ROM module or flash ROM of the Super CAP T/II T and the
Super CAPiT and placed in the mounted state.
In addition, when the user programs created by the machine
tool builder and the FANUC–supplied system programs are
removed from the ROM module or flash ROM of the Super
CAP T/II T and the Super CAPiT or erased from the flash
ROM, all programs must be erased from the part program
storage.
To erase all program from the part program storage, bit 0
(NE8) and bit 4 (NE9) of parameter No. 3202 must be set
to 0 with the protect key being canceled.
