A. MACRO PROGRAM EXAMPLE

B–61803E–1/10

APPENDIX

192

00010 O0001 ; Main

00020 N000 G202 P3 ; Screen clear

00030 #8505=0 ; Cursor OFF

00040 G243 X0 Y0 A1 B0 (SAMPLE PROGRAM)

00050 X2 Y3 (1 -- KEY TEST) ;

00060 X2 Y5 (2 -- COUSOR TEST) ;

00070 X2 Y7 (3 -- DISPLAY TEST) ;

00080 X2 Y9 (4 -- ADDRESS VARIABLE) ;

00090 X2 Y11 (5 -- CIRCLE) ;

00100 #8509=0033 ; Character string registration program No.

00110 #143=300 ;

00120 M98 P0011 ;

00130 N001 #142=#8501 ; Input variable read

00140 IF [#142 EQ 0] GOTO 99 ; Loop for which no key is depressed (including M99)

00150 IF [#142 LT 12] GOTO 99 ;

00160 IF [#142 GT 16] GOTO 99 ;

00170 #8500=[#142-11] *10 ;

00180 M99

00190 N099 M99 P1 ;

00200 ;

00210 ;

00220 ;

00230 ;

00240 ;

Menu display

Soft key display

Separate to program per softkeys
