Q. FS16i/18i/21i–TA Super CAPi T Concerning
CAP Control Module and User’s Module
590
D Example
The size of the user’s module 1 made by linking the CAPS macro
program and the user’s macro program for the auxiliary process is
256Kbytes.
And, the size of the user’s module 2 made by linking the other user’s
macro programs is 512Kbytes.
(1) The string file ”caps.src” is edited to modify the title of Super CAP
T/II T shown on the basic menu screen, and to modify the series and
the edition of the standard macro program shown on the system
configuration screen.
D Before Editing
⋅
⋅
⋅
/* 123456789012 ;
N9998 (’BB0H_ZZ’);
/* 12345678901234567890123456789012345678901234567890
N9999 (’FANUC SUPER CAPi T!’)
⋅
⋅
⋅
D After Editing
⋅
⋅
⋅
N9998 (’ABCDEFG’);
/* 12345678901234567890123456789012345678901234567890
N9999 (’DEBUG SYSTEM FOR SUPER CAPi T!’)
⋅
⋅
⋅
(2) Making the user’s macro programs for the auxiliary process
D O1004.SRC
D O1005.SRC
D O1006.SRC
(3) Making the user’s macro programs for machining
D USR_PRG.SRC
Q.8
EXAMPLE OF
MAKING USER’S
MODULE
Q.8.1
Making Programs
The string of the series and the edition of the user’s
program shown on the system configuration
screen.
The string of the title of Super CAP
T shown on the basic menu screen
Previous page
Next page
