(9) When loading terminates normally, the following message is
displayed. Pressing numeric key 1 starts the Series 16/18–A and
enables the executor to execute the macros loaded in the RAM.
MACRO COMPILER/EXECUTOR P–CODE LOADER
(I/O PARAMETERS) (DATA TRANSFER)
ADRxxxxxxH:xx
I/O CHANNEL = 0 (MAPPING – 1MB)
I/O UNIT = 0 *ā*ā*ā*ā*ā*ā*ā*ā*ā*ā*ā*ā*ā*ā*
BAUDRATE =11 *ā*ā*ā*ā*__________
STOP BIT = 1 _______________
INPUT CODE = 1 _______________
_______________
_______________
_______________
_______________
LOADING END : TOTAL xxxxxxxxBYTES
PUSH 1 KEY : CNC START WITH executor
When loading terminates normally for the Series 16/18-TTA, the
following message is displayed.
Pressing numeric key 1 returns to the screen in step (4). Select the
next tool post on the screen.
MACRO COMPILER/EXECUTOR P–CODE LOADER
HEAD 1
(I/O PARAMETERS) (DATA TRANSFER)
ADRxxxxxxH:xx
I/O CHANNEL = 0 (MAPPING – 1MB)
I/O UNIT = 0 *ā*ā*ā*ā*ā*ā*ā*ā*ā*ā*ā*ā*ā*ā*
BAUDRATE =11 *ā*ā*ā*ā*__________
STOP BIT = 1 _______________
INPUT CODE = 1 _______________
_______________
_______________
_______________
_______________
LOADING END : TOTAL xxxxxxxxBYTES
PUSH 1 KEY : RETURN TO HEAD SELECTION
