1. Fanuc
  2. SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor

SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor Programming manual Page 393

Programming manual
B–61803E–1/10
APPENDIX
E. FANUC Super CAP T/CAP II T MACRO
COMPILER/EXECUTOR (Series 16/18)
and Super Capi T Macro Compiler/
EXECUTOR (Series 16i/18i/21iT)
383
Macro
variable
Corresponding
data
Processes in which
the variable can be
referred to
Description
#20718 M code for specifying the direction of rotation about the milling
axis
– When bit 2 of parameter No. 9774 is 0, the tools to be used
rotate in the :
[3] : Normal direction
[4] : Reverse direction
– When bit 2 of parameter No. 9774 is 1, the tools to be used
rotate in the :
[Setting in parameter No.9877] :
Normal direction
[Setting in parameter No.9878] :
Reverse direction
If the settings in parameters No.9877 and No.9878 are zero or
100 or more, no value is specified.
All C-axis processes Tool data
PRM No.9774#2
PRM No.9877
PRM No.9878
#20717
<Ver.1>
<Ver.2 or
later>
Limit on finishing feed amount Bar machining, Trac-
ing, End face, and Tra-
peozoid groove
Cutting condition
data
#20716
<Ver.1>
<Ver.2 or
later>
Limit on finishing feed amount Automatic residual
machining of bars
Cutting condition
data
#20715 When a program is completed, codes T0; and G28; are :
0 : Output
1 : Not output
All processes PRM No.9774#4
#20714 When a process is completed, code M01 is :
0 : Not output
1 : Output
All processes PRM No.9774#3
#20713
#20712 The optional C-axis conversational programming function is
0 : Provided
1 : Not provided
All processes
#20711
#20710 Geometric compensation number for the tool to be used All processes Process data
#20709 Geometric compensation number for the tool to be used for
automatic residual machining
Bar machining Process data
#20708
<Ver.1>
<Ver.2 or
later>
For the chuck/tailstock barrier function,
0: The second stored stroke limit is used.
1: The NC’s chuck/tailstock barrier function is used.
All processes Option parameter
#20707
<Ver.1>
<Ver.2 or
later>
Chuck number All processes Initial setting
#20706
<Ver.1>
<Ver.2 or
later>
Tail stock number All processes Initial setting
