1. Fanuc
  2. SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor

SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor Programming manual Page 441

Programming manual
B–61803E–1/10
APPENDIX
E. FANUC Super CAP T/CAP II T MACRO
COMPILER/EXECUTOR (Series 16/18)
and Super Capi T Macro Compiler/
EXECUTOR (Series 16i/18i/21iT)
431
NOTE
The start point command G10 P90000 for animated
simulation, command G10 P90001 for drawing a straight
line, and command G10 P90002 or G10 P90003 for
drawing an arc specify the blank figure. The figure must be
closed.
(12)Start of the registration of a blank profile viewed from the end face
Command format G10 P90055 X_Z0. ;
Specifies the start of the registration of a blank figure viewed from the
end face as well as the diameter.
X: Diameter of the blank
(13)Registering the profile of the tool used for C-axis machining
Command format G10 P90056 X_Z_Q_R_ ;
Specifies the diameter, length, and tool type, as well as the
registration number in the graphic section.
X: Diameter of the tool
Z : Length of the tool
Q: Registration number of the tool in the graphic section
(17 to 32)
R = 0 : For a tool which cuts end faces
1 : For a tool which cuts side faces
(14)Size of an exploded view
Command format G10 P90057 X_Z_C_ ;
Specifies the area (X, Z) for which an exploded view is drawn and the
diameter (C) of a workpiece.
X: Z coordinate of the start point
Z : Z coordinate of the end point
C : Diameter of a workpiece
(15)Selecting the tool used in tool post 1
Command format G10 P90060 Q_R_ ;
Selects the tool to be used in tool post 1 and specifies the registration
number of the tool in the graphic section.
Q : Registration number of the tool (1 to 16) in the graphic
section
When the number is 0, no graphics are displayed.
R : Axes to which the mirror function is applied to generate the
figure of the tool
= 0 : X-axis off, Z-axis off
= 1 : X-axis on, Z-axis off
= 2 : X-axis off, Z-axis on
= 3 : X-axis on, Z-axis on
NOTE
When the conversational programming function is used in
FANUC Super CAP T/II T and Super CAPi T, the registration
number of the tool in the graphic section can be read from
macro variable No. 20705 or 20704 (variable No. 20704 is
used for the tool used for residual machining in bar
machining).
