APPENDIX
P. MACRO EXECUTORS
FOR THE Series 20i
571
#7 #6 #5 #4 #3 #2 #1 #0
Compile parameter
9101 YCNV
1: Displays the machining guidance screen (CUSTOM
screen) at the position lower than the normal display
position by one line. (This bit must be set to 1 when
FANUC sample programs are used.)
0: Displays the screen at the normal display position.
(5) Setting for extended interactive macro variables
Compile parameter
9004 Number of extended interactive macro variables used
When the ”GAIDNS” parameter bit, described earlier, is set to 1, the
extended interactive macro variable #10100 and above can be used. The
number of variables that can be used is the same as that in macro executors
other than those of the Series 20i. The part program storage is used
according to the number of variables that are set.
When the parameter bit is set to 0, the extended interactive macro variable
#20000 and above can be used. Except this, the above description applies.
(6) Compile parameters for Series 20i–TA FANUC sample programs
To use FANUC sample programs in the Series 20i–TA, the following
compile parameters must be set. Those bits that are named must be
set to 1, while the numeric parameters must be set to the specified
numeric values. For details of each parameter, see Appendix J,
”Parameters.”
#7 #6 #5 #4 #3 #2 #1 #0
Compile parameter
9000 TCF20
#7 #6 #5 #4 #3 #2 #1 #0
Compile parameter
9001 GAIDNS SEQN
#7 #6 #5 #4 #3 #2 #1 #0
Compile parameter
9002 EXT1 PWSR DAUX
#7 #6 #5 #4 #3 #2 #1 #0
Compile parameter
9003 HRGR ONMS
#7 #6 #5 #4 #3 #2 #1 #0
Compile parameter
9004 HRGC
#7 #6 #5 #4 #3 #2 #1 #0
Compile parameter
9006 CNCH STDM
#7 #6 #5 #4 #3 #2 #1 #0
Compile parameter
9007 RSAT
